Key Features
🔬 Advanced 3-Part Automated Analysis
-
This 3-part automated hematology analyzer utilizes proven impedance technology for accurate WBC, RBC, and PLT counting, along with a cyanide-free reagent for hemoglobin measurement.
-
Provides 19 comprehensive parameters, including a complete 3-part WBC differential (Lymphocytes, Mid-cells, Granulocytes) and essential RBC/PLT indices, supported by 3 detailed histograms.
-
Features exclusive detailed flagging for WBC, RBC, and PLT abnormalities—a capability rarely seen in 3-part analyzers—enhancing diagnostic insight and reducing manual review.
🏗️ Compact & Space-Optimized Design
-
With a footprint similar to a 17-inch laptop (Dimensions: 410mm × 300mm × 400mm; Weight: ≤20 kg), the BC-20S maximizes lab space without compromising functionality.
-
Internal storage for lyse reagent eliminates external bottles, freeing up bench space and simplifying laboratory workflow.
-
Ideal for clinics, physician offices, pediatric units, and labs with limited physical space.
⚡ Enhanced Efficiency & Throughput
-
Delivers a throughput of 40 samples per hour, ensuring timely processing for routine testing.
-
Requires only 9 µL of whole blood per test, making it perfect for pediatric, geriatric, and capillary blood samples.
-
Supports both whole blood and pre-diluted modes (20 µL), offering flexibility for various sample types and volumes.
🖥️ Intuitive User Experience
-
Features an 8.4-inch TFT color touch screen with user-friendly software designed to streamline operation and training.
-
Offers multi-language support and powerful data management with a storage capacity of 200,000 results, including numeric and graphical data.
-
Equipped with 4 USB ports for connecting peripherals (printer, barcode reader, keyboard, mouse) and supports bi-directional LIS communication via HL7 protocol.
-
Optional Wi-Fi capability provides added flexibility for wireless data communication and integration.
🧪 Economical & Sustainable Operation
-
Utilizes only two routine reagents (M-30D Diluent & M-30CFL Lyse), with no need for separate cleanser or rinse—reducing both reagent count and overall consumption.
-
Offers flexible reagent packaging (normal and small sizes) to better match daily testing volume and minimize waste.
-
Designed for low maintenance and reliable performance, backed by Mindray’s global quality standards and responsive support network.
Technical Specifications
| Parameter |
Specification |
| Model |
BC-20S |
| Brand |
MINDRAY |
| Technology |
Impedance Method, Cyanide-Free HGB Test |
| Differential |
3-Part WBC (Lymph%, Mid%, Gran%) |
| Parameters |
19 parameters + 3 histograms |
| Throughput |
40 samples/hour |
| Sample Volume |
Whole Blood: 9 µL; Pre-diluted: 20 µL |
| Data Storage |
200,000 results |
| Display |
8.4-inch TFT Touch Screen |
| Connectivity |
LAN (HL7), USB × 4, Wi-Fi (optional), Bi-directional LIS |
| Operating Environment |
Temperature: 10°C–40°C; Humidity: 10–90%; Pressure: 70–106 kPa |
| Power Supply |
100–240V, ≤300VA, 50/60Hz |
| Dimensions & Weight |
410mm × 300mm × 400mm; ≤20 kg |
| Reagents |
M-30D Diluent, M-30CFL Lyse, Probe Cleanser (optional) |
Applications
-
Small clinics and private practices
-
Community health centers
-
Pediatric and neonatal care units
-
Veterinary laboratories (with appropriate validation)
-
Mobile medical units and point-of-care sites
Ordering Information
| Item |
Details |
| Model |
MINDRAY BC-20S |
| MOQ |
1 unit |
| Ship From |
Guangzhou, China |
| Shipping |
Flexible terms available |
| Price |
[Get Price] – Contact for a personalized quote |
Why Choose the MINDRAY BC-20S?
The BC-20S 3-part automated hematology analyzer redefines value and performance for compact laboratory settings. Its space-saving design, low sample volume, and exclusive flagging features provide clinical insights typically found only in larger systems. With reduced reagent needs, flexible connectivity, and user-centric software, the BC-20S empowers labs to deliver accurate, efficient hematology testing with confidence—truly embodying what a modern 3-part analyzer should be.
✅ For pricing details, technical support, or to request a product demonstration, please contact our sales team today.
