Key Features
🔬 Advanced 5-Part Automated Hematology Analysis
-
This reliable automated analyzer in hematology employs impedance technology for accurate WBC, RBC, and PLT counting, combined with cyanide-free hemoglobin testing for safety and compliance.
-
Utilizes Hydrodynamic Focus-Free + Super Blue LED Scatter technology for precise 5-part WBC differentiation (Lymphocytes, Monocytes, Neutrophils, Eosinophils, Basophils).
-
Delivers 25 reportable parameters plus 4 research parameters (IMM%, IMM#, ALY%, ALY#), supported by 3 histograms and 1 detailed scattergram for complete morphological insight.
⚡ High Throughput with Minimal Sample Volume
-
Processes up to 60 samples per hour, ensuring rapid turnaround for routine and urgent testing.
-
Requires only 15.6 µL of whole blood or capillary blood for a complete CBC+DIFF analysis, making it especially suitable for pediatric, geriatric, and limited-volume samples.
-
Also supports pre-diluted mode (20.0 µL) for flexible sample handling.
🖥️ Intuitive Operation & Smart Design
-
Features a 10.4-inch TFT color touch screen with an intuitive interface for easy navigation and operation.
-
Offers a generous data storage capacity of 35,000 results, including histograms, facilitating patient trend analysis and data management.
-
Designed with low-voltage operation (24V DC) for enhanced safety and energy efficiency.
🧪 Economical & Low-Maintenance Operation
-
Requires only three routine reagents (Diluent, Lyse, Cleaner) plus optional maintenance bleach, minimizing inventory complexity and consumable costs.
-
Engineered for low reagent consumption and minimal daily maintenance, thanks to its streamlined internal fluidics and self-cleaning functions.
-
Compact footprint and robust construction ensure reliable performance with reduced downtime.
🔌 Safe & Reliable Performance
-
Operates under safe low-voltage DC power (24V), reducing electrical risks and supporting stable operation in diverse laboratory environments.
-
Built with quality components and backed by YSENMED’s trusted manufacturing standards, ensuring consistent accuracy and long-term reliability.
Technical Specifications
| Parameter |
Specification |
| Model |
EDAN AKH50 |
| Brand |
ArKang |
| Technology |
Impedance Method, Cyanide-Free HGB, Hydrodynamic Focus-Free + Super Blue LED Scatter |
| Differential |
5-Part WBC (Lymphocytes, Monocytes, Neutrophils, Eosinophils, Basophils) |
| Reportable Parameters |
25 |
| Research Parameters |
4 (IMM%, IMM#, ALY%, ALY#) |
| Throughput |
60 samples/hour |
| Sample Volume |
Whole Blood/Capillary: 15.6 µL; Pre-diluted: 20.0 µL |
| Data Storage |
35,000 results (including histograms) |
| Display |
10.4-inch TFT Touch Screen |
| Power Supply |
24V DC (safe low voltage) |
| Reagents |
Diluent, Lyse, Cleaner; Maintenance: Bleach |
| Dimensions |
Compact design optimized for bench-top use |
Applications
-
Hospital and clinical laboratories
-
Independent diagnostic labs
-
Pediatric and family care clinics
-
Community health centers
-
Research and academic institutions
Ordering Information
| Item |
Details |
| Model |
EDAN H50 |
| Brand |
ArKang |
| MOQ |
1 unit |
| Ship From |
Guangzhou, China |
| Shipping |
Flexible terms available |
| Price |
[Get Price] – Contact for a personalized quote |
Why Choose the EDAN AKH50?
The EDAN H50 automated analyzer in hematology combines precision, efficiency, and ease of use in one compact system. Its innovative optical design, low sample volume, and economical operation make it a smart investment for laboratories aiming to enhance diagnostic capabilities without increasing operational complexity. Whether for routine screening or detailed differential analysis, the EDAN H50 delivers consistent, accurate results you can trust.
✅ For pricing, technical details, or to schedule a product demonstration, please contact our sales team.
