Key Features
🔬 Advanced 5-Part Differential Technology
-
This 5 part hematology analyzer uses tri-angular laser scattering and flow cytometry for precise WBC differentiation into five populations: neutrophils, lymphocytes, monocytes, eosinophils, and basophils.
-
Features an independent BASO counting channel for enhanced accuracy in basophil measurement.
-
Provides 29 comprehensive parameters, including 4 research parameters (ALY#, ALY%, LIC#, LIC%), along with WBC, RBC, and PLT histograms, and 2D/3D scattergrams for detailed morphological analysis.
⚡ High Efficiency & Throughput
-
Delivers a consistent throughput of 60 samples per hour in both CBC and CBC+DIFF modes.
-
Low sample consumption: only 15µL for whole blood and 20µL for pre-diluted samples.
-
Minimal carry-over and excellent precision with CVs ≤2.0% for WBC, ≤1.5% for RBC, and ≤4.0% for PLT.
🧪 Integrated Reagent System
-
Utilizes three dedicated reagents: RD-50 Diluent, RL-50D Lyse, and RL-50H Lyse.
-
Compatible with original quality control (QC) materials and calibrators for ensured accuracy and traceability.
🖥️ Smart Connectivity & User-Friendly Design
-
Runs on an integrated Windows system with a 10.4-inch color touch screen for intuitive operation.
-
Supports bi-directional LIS communication via LAN and includes 4 USB ports for easy data transfer and peripheral connection.
-
Onboard storage for up to 100,000 test results, with an optional barcode reader, mouse, keyboard, and external printer.
📦 Compact & Reliable Build
-
Compact dimensions (365 x 470 x 525 mm) and lightweight design (31 kg), suitable for labs with limited space.
-
Equipped with a built-in thermal printer for immediate report generation.
-
Operates in a wide environmental range: 10°C–30°C, ≤85% humidity, with universal power compatibility (110V–240V, 50Hz/60Hz).
Technical Specifications
| Parameter |
Details |
| Model |
Hematray 51 |
| Brand |
ArKang |
| Analysis Principle |
Electrical impedance, Colorimetry, Laser scattering |
| Differential |
5-part hematology analyzer (NEU, LYM, MON, EOS, BAS) |
| Parameters |
29 parameters + 3 histograms + 4 scattergrams |
| Throughput |
60 samples/hour |
| Sample Types |
Whole Blood, Peripheral Blood, Pre-diluted Blood |
| Sample Volume |
Whole Blood: 15µL; Pre-diluted: 20µL |
| Reagents |
RD-50 Diluent, RL-50D Lyse, RL-50H Lyse |
| Data Storage |
100,000 results |
| Display |
10.4-inch color touch screen |
| Connectivity |
LAN, USB x 4, bi-directional LIS |
| Printer |
Internal thermal printer |
| Dimensions & Weight |
365 x 470 x 525 mm; 31 kg |
| Power Supply |
110V–240V, 50Hz/60Hz, 400VA |
Applications
-
Hospital clinical laboratories
-
Independent diagnostic centers
-
Research and academic institutions
-
Blood donation centers
-
Veterinary clinics (with appropriate validation)
Ordering Information
| Item |
Description |
| Model |
AK-Hematray 51 |
| MOQ |
1 unit |
| Ship From |
Guangzhou, China |
| Shipping |
Flexible terms to suit customer requirements |
| Price |
[Get Price] – Contact for quotation |
Why Choose the AK-Hematray 51?
The AK-Hematray 51 5 part hematology analyzer combines cutting-edge laser-based differentiation, high-speed processing, and a compact, user-friendly design. With its ability to deliver 29 parameters, low sample volume requirements, and robust data management, it stands out as a cost-effective and reliable choice for laboratories aiming to enhance diagnostic accuracy and workflow efficiency.
✅ For pricing, technical details, or a product demonstration, please contact our sales team.
