Key Features & Benefits
-
Dedicated Cardiac Probe: Phased array design optimized for getting between the ribs for clear cardiac imaging.
-
True Wireless Freedom: Connect via high-speed 5G WiFi (802.11n) for cable-free operation and enhanced maneuverability during examinations.
-
All-in-One Design: The entire ultrasound system is integrated into the probe, eliminating the need for a bulky main console.
-
Long-Lasting & Replaceable Battery: Features a powerful 2600mAh battery providing up to 3 hours of continuous scanning, and it is user-replaceable for extended device life.
-
Advanced Software Suite: Comprehensive adjustable parameters and measurement tools rival those of full-sized systems.
-
Multi-Language Support: Software interface available in multiple languages including English, Chinese, Spanish, French, German, and more for global use.
-
Modern Charging Solution: Includes a convenient wireless charger for easy power management.
Technical Specifications
Software & Measurement Capabilities
Adjustable Parameters:
Gain (GN), Depth (D), Enhancement (ENH), Dynamic Range (DR), Frequency (F), Focus Position, PRF, Wall Filter (WF), Mode, 8-point TGC, Biopsy, Annotation, Page Navigation.
Comprehensive Measurement Tools:
-
B-Mode: Length, Area/Circumference, Angle, Trace, Distance.
-
B+M Mode: Heart Rate, Time, Distance.
-
B+PW Mode: Velocity, Heart Rate (2), S/D Ratio, Depth.
Playback: 100, 200, 500, or 1000 frames optional.
Shipping & Ordering Information
-
Minimum Order Quantity (MOQ): 1 Unit
-
Shipping From: Guangzhou, China
-
Shipping Methods: Available by Air or Sea
